| Customization: | Available |
|---|---|
| Warranty: | 24months |
| Type: | Drum Wood Sander |
| Quantity: | |
|---|---|
1.automatic floating, effectively refuse over thick workpiece
2.automatic compensation with maximum c thickness of1mm.
3.profile welded frame with manual aging treatment.
4.servo motor lifting to achieve the accuracy of 0.01mm.
5.central information processing system, each electromagnet segment independently adjusted and controlled
6.edge protection
7.scanning distance 16-22mm
| Working Width | 60~1350mm |
| Working Thickness | 3~120mm |
| Working Length | ≥300mm |
| Size of Sanding Belt (W×C) | 1350x2620mm |
| Feeding Speed | 7-20m/min |
| Main Motor Power | 15kW.15kW |
| Working Air Pressure | 0.55Mpa |
| Consumption of Compressed Air | 1.5m³/min |
| Volume of Sucked Air | 12000m³/h |
| Speed of Sucked Air | 25m/s |
| Overall Dimension (L×W×H) | 2750x2250x2270mm |
| Net Weight | 5750kg |
Main motors with thermal relay protection;
SIMENS PLC
MCGS/ SIMENS Touch screen.
Main bearing: NSK/TR
Pneumatic components AIRTAC (TAIWAN)
Optoelctronic switch: BANNER/AB (USA)
3-color caution light;
Emergency stop button on both in-feed and out-feed ends;
Belt error/pressure error/ feeding error/ protection.
